HOME / PLANTS/ Charcoal Making Machine

Small Charcoal Making Machine

used to turn biomass or other waste into charcoal in an easy way.
12 m³/h/batch - 40 m³/h/batch
Small charcoal making machine is used to turn biomass or other waste into charcoal in an easy way. This machine is also called batch charcoal making machine. Sure-Origin machines are a combination structure. They are easy to be delivered and installed. When choosing this type of machine, customers can put it into production quickly. Besides machines, Sure-Origin provides a series of biomass or other waste into charcoal solutions. Just send you detailed requirements to us.
Raw Materials
There are many kinds of waste that are good materials for carbonization. They are biomass waste, sewage sludge waste, municipal solid waste, food waste, etc.
Biomass waste: sawdust, bamboo, wood, coconut shell, olive shells, palm kernel shell, corn stalk, coffee shell, reed pole, peanut shell, etc.
Sewage sludge waste: civil sludge, municipal sludge, river sludge, industrial sludge, etc.
MSW: civil waste, food waste, industrial waste, electronic waste, etc.
Working Process
Feeding the raw materials by manual labor.
After heating the small charcoal reactor, the raw materials will go through the following process in the sealed reactor, including drying and carbonization. The reaction time depends on the category, size, and moisture of materials. Normally, the reaction circle is about 3-8 hours.
When the carbonization of raw materials is finished, customers could take some time to cool the final charcoal. In general, the cooling time is about 5-8 hours.
Sure-Origin small charcoal making machine carbonizes 12-40m³ of raw materials. When you have some waste raw materials and wanna find waste in charcoal business, contact us. Sure-Origin provides different kinds of waste solutions, including project feasibility, drawing design, custom machine, shipping route offering, installment guidance, etc. Contact us to get your ideal business.
Features
1. Materials are selected from good materials.
2. Parts are coming from a famous brand with guaranteed quality.
3. It has a combination pack that is easy to transport and install.
4. Workers hold some simple skills to operate this line.
5. Weight is light. Customers could relocate the site easily.
6. The installation area is small. The land investment cost is reduced.
7. There are several heating solutions. And we provide customized solutions to customers.
Applications
The end products have wide applications in all fields. They are charcoal, tar, wood vinegar, and bio-gas. These products are sold directly at a good price. And these products are also for personal use if investors have this demand.

Charcoal Uses
Material of producing high-quality steel.
In non-ferrous metal production, charcoal is often used as a surface flux.
People often use charcoal as a fuel for heating, barbecue and hot pot.
It is a slow-release agent for pesticides or fertilizers.

Tar Uses
It is mainly used as a disinfectant and preservative.
After processing, creosote, anti-polymerization agent, flotation foaming agent, wood pitch, etc. can be obtained.
It is used in medicine, synthetic rubber and metallurgy sectors.
It is a chemical raw material.

Wood Vinegar Uses
It is good foliar fertilizer for soil improvement.
Good meterails of antivirus deodorant deodorant.
Material of preservative liquid.
Material of plant growth regulator.
Great material of repellents for insect pests.
Material of food preservation.

Biogas Uses
It is used to heat the carbonization reactor directly.
It is a good fuel used to heat all heating devices in the industrial factories.
After purification, it can be used to generate electricity.
The biogas can be collected and sold to industries directly.
Technical Parameters
Sure-Origin provides 3 models with a capacity of 12-40m³ per furnace. They are TMT-J12, TMT-J18, and TMT-J40. See the detailed parameters of charcoal making machines.
Model TMT-J12 TMT-J18 TMT-J40
Input Capacity 12m³/h/batch 18m³/h/batch 40m³/h/batch
Reactor Size φ1900mm*L4500mm φ1900mm*L6600mm φ2800mm*L7100mm
Land for Equipment (L*W*H, Standard Configuration) 9m*6m*6m 12m*6m*7m 15m*18m*7m
Weight (Standard Configuration) 18T 22T 34T
Energy Consumption (Standard Configuration) 11kw/h 13.5kw/h 25kw/h
Working Method Batch
Feeding Requirement /
Structure Horizontal rotation
Speed 0-2RPM
Control Method Control by buttons
Pressure Micro negative pressure
Reactor Material Q245R Q245R Q245R
Heating Material Diesel, natural gas, heavy oil, biomas, etc. Diesel, natural gas, heavy oil, biomas, etc. Diesel, natural gas, heavy oil, biomas, etc.
Heating Method Direct heating Direct heating Direct heating
Noise (dB) ≤80 ≤80 ≤80
Condenser Circulating water cooling Circulating water cooling Circulating water cooling
Rotation Method External gear rotation External gear rotation External gear rotation

Why Choose Sure-Origin Small Charcoal Making Machines?
Safety Guarantee
Sure-Origin small machines have many different safety designs and parts to guarantee safe operation, including thermometers, pressure gauges, safety valves, explosion-proof valves, etc. Moreover, the materials of machines have high resistance. So, the safety of the entire charcoal production process can be guaranteed.

Strict Quality Control
Firstly, Sure-Origin adopts good materials to manufacture equipment. Secondly, Sure-Origin has certificates related to quality and emission. Thirdly, Sure-Origin machines have been strictly tested by a professional team. We can provide inspection reports to customers. Finally, Sure-Origin team will check every part before delivery.

Top Three in the Chinese Industry
Sure-Origin biomass pyrolysis plants have been exported to 30+ countries. And our customers have good feedback on our machines and services. Sure-Origin, as an experienced manufacturer, has a professional team, large factory, exclusive technology, and flexible solutions. We are recognized as the top three in the industry.

One-stop Services
From consulting to project running, Sure-Origin provides one-stop services to customers. We not only provide flexible small charcoal production lines but also offer waste to charcoal solutions. We help you to make project drawings, project evaluations, project profitability reports, one-stop turnkey projects, installment support, operation support, etc.
Complete recycling solutions, contact our experts today

SERVICE

Reliability throughout the lifetime of your unit!
Technical Advice and Design
Sure Origin engineers will “investigate” with the customer in order to define the proper machinery, proposing the best custom-made system. According to the customer needs about materials treatment, the capacity requirement and the warehouse layout, we will find the best solution. Sure Origin always strives for the best quality and highest possible recovery rates and outputs.
Material Testing
We invite you to send us samples of your materials with a description of your reduction requirements. Our testing laboratory will gladly analyze your needs and send you a sample of the finished product for your approval. We will provide you a confidential technical analysis with the results and data.
Testing Machine Before Delivery
In order to provide customers with the best equipment quality, we provide testing machine service before delivery to ensure the normal operation of each equipment.
Installation & Commissioning & Training
Sure Origin's service for recycling machines is now available worldwide. Sure Origin’s skilled technicians are available to assist with onsite installation, commissioning & training on request. This will enable customers to optimize the performance of their new plant. Customers will be briefed on all aspects relating to operation and maintenance by a Sure Origin technician. Dimensional drawings together with service requirements will be provided prior to delivery of the equipment. This will allow the customer to prepare the site and allow them to commence production in a timely fashion.
Spare Parts
Do you need advice about the right parts for your recycling machines? Our service and support experts will help find the right part and ship it to meet your needs. Sure Origin holds a adequately inventory of spare parts and their efficient service personnel will ensure that any required part will be dispatched without delay. Delivery of the spare parts may be by air, sea or courier depending on the urgency of the situation. Putting your trust in parts from Sure Origin guarantees the continuity of your work processes.
Quick Response
We assure you of a detailed reply within 24 hours upon receipt of your request, and providing you with professional advice.
