PCB Component Dismantling Machine

PCB component dismantling machine s used to dismantle the electronic components from waste circuit boards, CCL, waste computer mother boards, waste cell phone motherboards, waste TV boards and PCB scrap etc. Electronic circuit board and other electronic components contain a large number of precious metal. By using this machine, all the ferrous metals and precious metals can be separated effectively and cleanly, and high value metals such as copper, aluminum, tin, gold, silver and platinum can be obtained.
Working Principle
PCB dismantling machine can be powered by nature gas or electricity. The roller part can be heated up to 400 degree. The tin on circuit board will be melted, and the electronic components(card slots, capacitors, chips, etc.) will be dropped from the circuit board with the running of the main engine. You can also use a vibrating screen to further sort the components.
The inner tank of the circuit board high temperature dismantling machine uses the 6mm-thick No. 45 anti-skid steel plate, and the outer wall is insulated with the insulating cotton to prevent the loss of temperature and the corresponding production technology; safe and reliable, stable performance, durable and other characteristics, use the automatic heating device of automatic temperature control, forced air supply and flame-out self-ignition control, and set up the automatic memory preservation of temperature per time.
Features
1. Full automatic working, save labor, two persons are enough.
2. Tin remove and dismantling components at one step.
3. Automatic temperature controlled by our heating system.
4. Large capacity: 200kg/h,300kg/h,500kg/h.
5. Operating safety and easily.
6. Less damage to the components,keep the precious metals no losing.
7. Mother board and components can be proceed respectively in the next step to improve economic benefits.
8. Friendly to the air environment,all the smoke processing by the waste gas treatment system.
Complete recycling solutions, contact our experts today

SERVICE

Reliability throughout the lifetime of your unit!
Technical Advice and Design
Sure Origin engineers will “investigate” with the customer in order to define the proper machinery, proposing the best custom-made system. According to the customer needs about materials treatment, the capacity requirement and the warehouse layout, we will find the best solution. Sure Origin always strives for the best quality and highest possible recovery rates and outputs.
Material Testing
We invite you to send us samples of your materials with a description of your reduction requirements. Our testing laboratory will gladly analyze your needs and send you a sample of the finished product for your approval. We will provide you a confidential technical analysis with the results and data.
Testing Machine Before Delivery
In order to provide customers with the best equipment quality, we provide testing machine service before delivery to ensure the normal operation of each equipment.
Installation & Commissioning & Training
Sure Origin's service for recycling machines is now available worldwide. Sure Origin’s skilled technicians are available to assist with onsite installation, commissioning & training on request. This will enable customers to optimize the performance of their new plant. Customers will be briefed on all aspects relating to operation and maintenance by a Sure Origin technician. Dimensional drawings together with service requirements will be provided prior to delivery of the equipment. This will allow the customer to prepare the site and allow them to commence production in a timely fashion.
Spare Parts
Do you need advice about the right parts for your recycling machines? Our service and support experts will help find the right part and ship it to meet your needs. Sure Origin holds a adequately inventory of spare parts and their efficient service personnel will ensure that any required part will be dispatched without delay. Delivery of the spare parts may be by air, sea or courier depending on the urgency of the situation. Putting your trust in parts from Sure Origin guarantees the continuity of your work processes.
Quick Response
We assure you of a detailed reply within 24 hours upon receipt of your request, and providing you with professional advice.
