Palm Kernel Shell Charcoal Making Machine, PKS Carbonization Machine

Palm Kernel Shell Charcoal Making Machine

Palm kernel shell charcoal making machine is applied to make profitable palm kernel shell charcoal. With this machine, palm kernel shell waste can be turned into the fuel efficiently used in our daily life. TM-Machine offers batch and continuous machines at an affordable price. Moreover, as a manufacturer, we are responsible for after-sales services.

[email protected]

Applications

Palm Kernel Shell Charcoal
BBQ/hookah charcoal or heating fuel.
Attach heavy metal in the soil.
Materials for making bricks with clay.

Tar
Anti-insect fungicide
Pesticide neutralization
Soil conditioner

Wood Vinegar
Materials for permeability-reducing agent for construction.
Fertilizer that improves soil quality.

Biogas
It is as the fuel in carbonization plant.
Applied in greenhouse heating.
It is used to make electricity by generator.

Advantages

1. Made by Good Materials
The reactor is mainly employed stainless steel 310s material. It has high-temperature resistance, which greatly improves the life span. Moreover, other parts are adopted good brands, which have a long service life.

2. Affordable Palm Kernel Shell Charcoal Making Machine Price
TM-Machine machines price not reflects in the machine quality but also long-term services.

3. Environmental-friendly Dedusting System
Firstly, there is no dust flying on the site. Through many tries, the discharging at the end of the reactor won’t have the situation of dusting flying. Moreover, the discharger uses a water cooling system, which reduces the temperature.

4. Secondly, the dedusting system helps to purify the smoke. There are four processes, including water washing, water spray, absorption. After being processed by these three processes, the smoke meets emission standards. If the local government has higher emissions, add an activated charcoal absorption procedure.

5. Energy-saving System to Reduce Fuel Cost
The light oil gas can’t be liquefied by hydroseal. After desulfurization, it can be burned directly in the combustion chamber.

6. Safety Guarantee
The explosion-proof valve at the end of the reactor.
PLC has an alarming button.
Explosion-proof hydroseal in the combustible flue.
The gas and smoke are induced by the draft fan.

Technical Parameters

Model	TMT-J12	TMT-J18	TMT-J40	TMT-05 Pro (skid-mounted)	TMT-10	TMT-30	TMT-50
Input Capacity	12m³/batch	18m³/batch	40m³/batch	0.3-0.5m³/h	2-4m³/h	7-9m³/h	10-15m³/h
Reactor Size	φ1900mm * L4500mm	φ1900mm * L6600mm	φ2800mm * L7100mm	φ830mm * L5500mm	φ1300mm * L14051mm	φ1700mm * L14180mm	φ2000mm * L14260mm
Land for Equipment (LWH, Standard Configuration)	9m6m6m	12m6m7m	15m18m7m	10m8m3.9m	29m15m5m	30m15m8m	35m18m9m
Weight (Standard Configuration)	18T	22T	34T	15T	35T	35T	49T
Energy Consumption (Standard Configuration)	11kw/h	13.5kw/h	25kw/h	31kw/h	34.7kw/h	61.5kw/h	116kw/h
Working Method	Batch			Fully continuous
Feeding Requirement	/			Size: ≤20mm; moisture: ≤15%; strong liquidity
Structure	Horizontal rotation			Double barrel single hearth	Double barrel double hearth
Speed	0-2RPM			1-9RPM
Control Method	Control by buttons			Automatic control
Reactor Material	Q245R				Q245+310S
Pressure	Micro negative pressure
Heating Material	Diesel, natural gas, heavy oil, biomass, etc.
Heating Method	Direct heating
Noise (dB)	≤80
Condenser	Circulating water cooling
Rotation Method	External gear rotation

Recycling Plants & Equipment

Excellent technologies for waste recycling

Mobile Biochar Machine

for converting a small amount of biomass waste and industrial waste into biomass charcoal.

Small Charcoal Making Machine

used to turn biomass or other waste into charcoal in an easy way.

Continuous Charcoal Making Machine
