Model | TMT-J12 | TMT-J18 | TMT-J40 | TMT-05 Pro (skid-mounted) | TMT-10 | TMT-30 | TMT-50 |
Input Capacity | 12m³/batch | 18m³/batch | 40m³/batch | 0.3-0.5m³/h | 2-4m³/h | 7-9m³/h | 10-15m³/h |
Reactor Size | φ1900mm * L4500mm | φ1900mm * L6600mm | φ2800mm * L7100mm | φ830mm * L5500mm | φ1300mm * L14051mm | φ1700mm * L14180mm | φ2000mm * L14260mm |
Land for Equipment (L*W*H, Standard Configuration) | 9m*6m*6m | 12m*6m*7m | 15m*18m*7m | 10m*8m*3.9m | 29m*15m*5m | 30m*15m*8m | 35m*18m*9m |
Weight (Standard Configuration) | 18T | 22T | 34T | 15T | 35T | 35T | 49T |
Energy Consumption (Standard Configuration) | 11kw/h | 13.5kw/h | 25kw/h | 31kw/h | 34.7kw/h | 61.5kw/h | 116kw/h |
Working Method | Batch | Fully continuous | |||||
Feeding Requirement | / | Size: ≤20mm; moisture: ≤15%; strong liquidity | |||||
Structure | Horizontal rotation | Double barrel single hearth | Double barrel double hearth | ||||
Speed | 0-2RPM | 1-9RPM | |||||
Control Method | Control by buttons | Automatic control | |||||
Reactor Material | Q245R | Q245+310S | |||||
Pressure | Micro negative pressure | ||||||
Heating Material | Diesel, natural gas, heavy oil, biomass, etc. | ||||||
Heating Method | Direct heating | ||||||
Noise (dB) | ≤80 | ||||||
Condenser | Circulating water cooling | ||||||
Rotation Method | External gear rotation |
Return on Investment of TMT-50 Wood Chips Carbonization Project in The Middle East Regin | ||||||||
Item | Details | Unit | Unit price/USD | Quantity | Amount/USD | Total amount | Remark | |
Fixed Investment Cost | Equipment | TMT-50 | Set | 250000 | 1 | 250000 | ||
Transportation | From China to Destination Port | Set | 90000 | 1 | 90000 | |||
From Port to Site | Set | 5800 | 1 | 5800 | ||||
Customs tax | 0.15 | Set | 37500 | 1 | 37500 | |||
Installation | Sure-Origin technician's salary | Day | 100 | 50 | 5000 | |||
Round -trip airtickets | Ea | 2420 | 2 | 4840 | ||||
Visa | Ea | 350 | 1 | 350 | ||||
Local welder | Day | 65 | 100 | 6500 | Two welders are needed | |||
Local plumber | Day | 65 | 20 | 1300 | ||||
Local labor | Day | 16.8 | 50 | 840 | ||||
Crane forklift etc. | Day | 80 | 30 | 2400 | ||||
Materials | Installation materials ready | Set | 3500 | 1 | 3500 | Foundation, pipe, etc. | ||
License | / | Ea | 2000 | 1 | 2000 | Environmental, firefighting, etc. | ||
Workshop | 500 | ㎡ | 160 | 500 | 80000 | |||
490030 | ||||||||
Operating Cost | Raw materials | Wood chips | Ton | 100 | 120 | 12000 | ||
Water | / | m³ | 1.76 | 3 | 5.28 | |||
Electricity | / | KWH | 0.11 | 2922 | 321.42 | |||
Fuel | Natural gas | Liter | 7.25 | 270 | 1957.5 | |||
Labor | / | People | 16.8 | 4 | 67.2 | |||
Maintenance | / | Day | 85 | 1 | 85 | |||
Depreciation | 8 years | Day | 209.3 | 1 | 209.3 | |||
Tax | 0.05 | 0 | ||||||
14645.7 | ||||||||
End Products Price | Biochar | 0.3 | Ton | 680 | 36 | 24480 | 30% of input | |
Wood vinegar | 0.08 | Ton | 1280 | 9.6 | 12288 | 8% of input | ||
Tar oil | 0.02 | Ton | 450 | 2.4 | 1080 | 2% of input | ||
37848 | ||||||||
Daily Income | 23202.3 | |||||||
Monthly Income | Working day | Day | 25 | 580057.5 | ||||
Yearly Income | Working day | Day | 300 | 6960690 |
