Straw Charcoal Making Machine, Straw Carbonization Furnace

Straw Charcoal Making Machine

Straw charcoal making machine can effectively convert agricultural waste – straw into biomass charcoal. If you invest in efficient TM-Machine charcoal making equipment to recycle straw, the final biomass charcoal is of high quality. Moreover, the whole production process does not pollute the surrounding environment. In addition, TM-Machine also provides a series of services, including program consulting services, installation services and so on.

[email protected]

Eco-friendly

In daily life, common disposal methods for straw include burning, making charcoal in charcoal kiln, cooking, composting and so on. Some methods cause very serious pollution to the environment. Some methods are inefficient and the final yield is extremely low. There are also methods that require large investment capital and long periods of time. We don’t recommend using these methods to recycle straws.
If the straw is recovered by TM-Machine carbonization equipment, the quality of the biomass charcoal is controllable. The entire production process is highly automated. And this equipment is equipped with a combustible gas recovery system and a de-dusting system. Not only does it not pollute the environment, but it can also recover and reuse the excess combustible gas in the production process. Why don’t you invest in this machine right now?

Raw Materials

TM-Machine charcoal making equipment can be used to recycle a variety of straws. When the moisture content of these straws is more than 20%, a dryer is required. Please see the categories below.
Wheat straw
Barley straw
Oat straw
Rye straw
Buckwheat Straw
Corn stalks
Cotton straw
Alfalfa straw
Other kinds of straw

Applications

The produced biomass charcoal can be made into rod charcoal, stick charcoal, hookah charcoal, charcoal powder, charcoal pellets, etc. They can be used for the following purposes.
Making stalks into charcoal is conducive to environmental protection and emission reduction;
Biochar can be used to improve soil;
Straw charcoal is a good fuel for hookah;
Charcoal can be used as fuel for barbecues;
It is alternatives to fuel in various plants, including cement plants, boiler plants, power plants, ceramic plants, etc.

Advantages

Flexible Choose on Type
TM-Machine offers three types of straw carbonization machine. They include seven models. These models could meet customers’ needs from all aspects, including output, working method, feeding method, degree of automation, energy heating method, heating energy type, exhaust gas treatment system, and so on. Besides, we also can provide customized feeding system and discharging system. Tell us your need.

Complete Recycling Solutions & Lines
TM-Machine, as manufacturers, doesn’t just offer a single set of biochar equipment. We can customize suitable carbonization production plans for customers according to customer needs and local conditions, including drawings, production line details, layout drawings, etc. At the same time, we also provide other additional production lines, including crushing line, drying line and charcoal briquettes production line.

Quality Assurance
TM-Machine has ISO, SGS, CE and other professional certificates. And, we have 10+ patents. These models have been developed, trialled and put into use by our R&D staff. They are the new generation of machines. The components of these straw charcoal equipment are sourced from quality-assured manufacturers and are durable. When the production of straw charcoal making furnace finishes, our quality control department and delivery department inspect and pack it.

Eco-friendly System & Energy Saving System
TM-Machine charcoal making equipment is equipped with a de-dusting system. It can treat the exhaust gas from the main furnace. The final exhaust gas meets the EU emission standard. In addition, there is a combustible gas recovery system. It treats combustible gas that cannot be liquefied in the condenser. The treated gas can be used for heating main furnace. And excess combustible gas can be burned through the exhaust combustion chamber.

Technical Parameters

TM-Machine offers three types of straw charcoal making equipment, including skid-mounted charcoal making machine, batch charcoal making equipment and continuous type. They are all equipped with de-dusting systems for exhaust gas treatment. They have different working methods and capacity.

Portable Straw Biochar Machine
Working hours: one furnace per day (require a cooling time)
Feeding method: manual feeding
Discharge method: automatic water-cooling discharging
Infrastructure work: not required
Occupied area: small
Degree of Automation: moderate
Target customers: Small scale biomass charcoal manufacturing business/mobile biomass charcoal production type

Batch Straw Charcoal Machine
Working hours: one furnace per day (require a cooling time)
Feeding method: manual feeding
Discharging method: manual discharging
Infrastructure work: required
Occupied area: medium
Degree of automation: moderate
Target customers: Customers who have requirements on the processing volume of raw materials or who have requirements on the final output

Continuous Machine
Working hours: work for 3-6 days continuously (not require cooling time)
Feeding method: automatic feeding
Discharge method: automatic water-cooling discharge
Infrastructure work: required
Occupied area: large
Degree of automation: high
Target customers: Large-scale biomass charcoal production business/customers with abundant raw materials

Model	TMT-J12	TMT-J18	TMT-J40	TMT-05 Pro (skid-mounted)	TMT-10	TMT-30	TMT-50
Input Capacity	12m³/batch	18m³/batch	40m³/batch	0.3-0.5m³/h	2-4m³/h	7-9m³/h	10-15m³/h
Reactor Size	φ1900mm * L4500mm	φ1900mm * L6600mm	φ2800mm * L7100mm	φ830mm * L5500mm	φ1300mm * L14051mm	φ1700mm * L14180mm	φ2000mm * L14260mm
Land for Equipment (LWH, Standard Configuration)	9m6m6m	12m6m7m	15m18m7m	10m8m3.9m	29m15m5m	30m15m8m	35m18m9m
Weight (Standard Configuration)	18T	22T	34T	15T	35T	35T	49T
Energy Consumption (Standard Configuration)	11kw/h	13.5kw/h	25kw/h	31kw/h	34.7kw/h	61.5kw/h	116kw/h
Working Method	Batch			Fully continuous
Feeding Requirement	/			Size: ≤20mm; moisture: ≤15%; strong liquidity
Structure	Horizontal rotation			Double barrel single hearth	Double barrel double hearth
Speed	0-2RPM			1-9RPM
Control Method	Control by buttons			Automatic control
Reactor Material	Q245R				Q245+310S
Pressure	Micro negative pressure
Heating Material	Diesel, natural gas, heavy oil, biomass, etc.
Heating Method	Direct heating
Noise (dB)	≤80
Condenser	Circulating water cooling
Rotation Method	External gear rotation
