Before Feeding
The requirement for bamboo size is no more than 2cm. The larger bamboo pieces need crushing by a crushing machine. The space size between bamboo pieces has a close relationship to the quality of bamboo biochar. Then, small bamboo pieces enter into the drying system. The excess water content will be removed.

Bamboo to Charcoal Process
Heat the chamber. After half hour later, screw automatic feeder pushes bamboo into carbonization reactor. If the temperature is over 350℃, the chemical change starts. The bamboo charcoal will be discharged on the same side.

Combustible Gas System
When bamboo is changed into charcoal, there are waste gas and waste smoke in the reactor. The waste gas enters into the cyclone dust collector and two condensers by an induced draft fan. The two procedures guarantee the cleanness of combustible gas. Accordingly, the combustible gas is able to provide heat for the reactor instead of other fuel.

Portable & Continuous Models – Two Options
The portal one has the following advantages: Firstly, takes 7-10 working days to install. Secondly, there is no need for fundamental work when install this charcoal manufacturing plant. Thirdly, it is easy to operate. Fourthly, the budget is small.

The advantages of the continuous one are described as the following: 1. It has a continuous and fully sealed working process; 2. We provide various options for feeders, dischargers and some small parts; 3. It has a small influence on the environment.

How to Guarantee Project Safety
For improving safety in the production process, we place a series of devices to monitor and control this machine.
1. Workers monitor the pressure and temperature through several parameters and pressure gauges.
2. In some key parts, there are pressure-relief valves.
3. This type adopts three stages of water cooling dischargers on the production line. It will greatly reduce the cooling time and improve safety.

Offer Quick Shipment and Installment
For small types, we arrange the delivery in 15-30 working days. And install it in 7-15 working days. For continuous types, Sure-Origin will ship them in 30-45 working days. Because there is a need to do some fundamental work before installing them. The whole establishment process needs 30-60 working days.

1-year Guarantee to Protect Investors’ Right
Sure-Origin offers a 1-year guarantee. Firstly, we will offer some wearing parts for free when shipping this machine. Secondly, it is available for us to dispatch engineers to help your project, including installment and training. Thirdly, we will give some call visits and technical support for investors.

1. Wide bamboo sources. Asia, as the biggest exporting area of bamboo. The bamboo is widely distributed in Asia. Therefore, it is easy for Asian customers to get raw materials.
2. Utilization of waste bamboo. Due to wide application of bamboo, there are substantial things made of bamboo, like furniture, handcraft, fence, etc. This waste can be made into charcoal by this machine.
3. Bamboo charcoal and by-products (wood vinegar and tar) have wide application in Asia.

End Products	Area	Usages
Charcoal	Daily life	• widely used as the fuel of BBQ.
		• used as the fuel in other industries.
	Agriculture	• attach heavy metal to improve the quality of the soil.
	Industry	• can be reprocessed into activated carbon.
		• used for construction bricks with clay.
		• widely used as fuel in industries such as steel and iron factories, ceramics, etc.
Biogas	Daily life	• widely used as fuel.
	Agriculture	• greenhouse agriculture heating.
	Industry	• used as fuel for heating or drying.
		• can be used for the generator to get electricity.
Wood vinegar, tar	Industry	• the great materials in shipbuilding and paint industry.
		• used as raw materials in chemical and medicine field.
	Agriculture	• used as plant nutrition regulates auxin or insecticide.

Return on Investment of TMT-50 Wood Chips Carbonization Project in The Middle East Regin
	Item	Details	Unit	Unit price/USD	Quantity	Amount/USD	Total amount	Remark
Fixed Investment Cost	Equipment	TMT-50	Set	250000	1	250000
	Transportation	From China to Destination Port	Set	90000	1	90000
		From Port to Site	Set	5800	1	5800
	Customs tax	0.15	Set	37500	1	37500
	Installation	Sure-Origin technician's salary	Day	100	50	5000
		Round -trip airtickets	Ea	2420	2	4840
		Visa	Ea	350	1	350
		Local welder	Day	65	100	6500		Two welders are needed
		Local plumber	Day	65	20	1300
		Local labor	Day	16.8	50	840
		Crane forklift etc.	Day	80	30	2400
	Materials	Installation materials ready	Set	3500	1	3500		Foundation, pipe, etc.
	License	/	Ea	2000	1	2000		Environmental, firefighting, etc.
	Workshop	500	㎡	160	500	80000
							490030
Operating Cost	Raw materials	Wood chips	Ton	100	120	12000
	Water	/	m³	1.76	3	5.28
	Electricity	/	KWH	0.11	2922	321.42
	Fuel	Natural gas	Liter	7.25	270	1957.5
	Labor	/	People	16.8	4	67.2
	Maintenance	/	Day	85	1	85
	Depreciation	8 years	Day	209.3	1	209.3
	Tax	0.05				0
							14645.7
End Products Price	Biochar	0.3	Ton	680	36	24480		30% of input
	Wood vinegar	0.08	Ton	1280	9.6	12288		8% of input
	Tar oil	0.02	Ton	450	2.4	1080		2% of input
							37848
Daily Income							23202.3
Monthly Income	Working day		Day	25			580057.5
Yearly Income	Working day		Day	300			6960690

Model	TMT-J12	TMT-J18	TMT-J40	TMT-05 Pro (skid-mounted)	TMT-10	TMT-30	TMT-50
Input Capacity	12m³/batch	18m³/batch	40m³/batch	0.3-0.5m³/h	2-4m³/h	7-9m³/h	10-15m³/h
Reactor Size	φ1900mm * L4500mm	φ1900mm * L6600mm	φ2800mm * L7100mm	φ830mm * L5500mm	φ1300mm * L14051mm	φ1700mm * L14180mm	φ2000mm * L14260mm
Land for Equipment (L*W*H, Standard Configuration)	9m*6m*6m	12m*6m*7m	15m*18m*7m	10m*8m*3.9m	29m*15m*5m	30m*15m*8m	35m*18m*9m
Weight (Standard Configuration)	18T	22T	34T	15T	35T	35T	49T
Energy Consumption (Standard Configuration)	11kw/h	13.5kw/h	25kw/h	31kw/h	34.7kw/h	61.5kw/h	116kw/h
Working Method	Batch			Fully continuous
Feeding Requirement	/			Size: ≤20mm; moisture: ≤15%; strong liquidity
Structure	Horizontal rotation			Double barrel single hearth	Double barrel double hearth
Speed	0-2RPM			1-9RPM
Control Method	Control by buttons			Automatic control
Reactor Material	Q245R				Q245+310S
Pressure	Micro negative pressure
Heating Material	Diesel, natural gas, heavy oil, biomass, etc.
Heating Method	Direct heating
Noise (dB)	≤80
Condenser	Circulating water cooling
Rotation Method	External gear rotation
