Shisha Charcoal Making Machine, Shisha Charcoal Production Line

Raw Materials

When you start this charcoal making business, prepare rich raw materials. The raw materials are coconut shells, bamboo, apple wood, olive wood, and other fruit wood. Shisha charcoal has high stability, no odor, smoke free, and long burning time by using this kind of natural thing.
Before processing materials, make sure that the moisture and size meet requirements. The moisture is less than 15%. The size is smaller than 20mm. Otherwise, dryers and crushing machine are needed.
After making sure the raw materials, you could consider getting a suitable shisha charcoal making machine to start this business. Sure-Origin offers shisha charcoal making line and solutions to customers. The shisha charcoal making line is composed of shishia charcoal making machine and shisha charcoal briquette making line.

Advantages

Manufacturing Advantage
The equipment is all welded with national standard steel; All machining parts are made of numerically controlled materials; Sure-Origin equipment has undergone a complete production process from raw material processing to quality inspection and testing.

IoT System
Customers could use the IoT system to master product information, equipment operation data and fault information in real time. Customers could set early warning values and early warning strategies for different parameters according to the attributes of each monitoring data.

Energy-saving and Environmental-friendly System
The green equipment adopts the inner and outer double-layer reactor and the double-return heating structure. First, the fuel-saving effect and carbonization effect is good. Our users have a very high praise rate. Second, the material is not in contact with the flue gas. It is not polluted with the hot air. Thermal efficiency increasesmore than doubled.

Strict Quality Control Process
Sure-Origin charcoal production equipment has a set of standard quality inspection process, including incoming inspection, cutting, welding, grinding, painting, and so on. We welcome customers to visit our manufacturing factory. We also welcome third-party inspection of the head for quality assessment at any time. Sure-Origin guarantees the quality.

Shisha Charcoal Briquette Machine

The standard moulds could be changed to make other shapes of shisha charcoal briquettes, for example, cube hookah Charcoal, instant shisha charcoal tablets, etc. If you have special requirement on shisha charcoal shape, contact us to make your ideal customized moulds.

Working Principle

The materials with the appropriate size and moisture is fed into the main shisha charcoal reactor manually or by a automatic feeder.
After heating the main shisha charcoal furnace, the temperature gradually rises. When the carbonization temperature is reached, the biomass carbonization process is completed in 15-20 minutes.
Biochar is discharged through water-cooling discharger or labor force.
The biomass charcoal is transported to the shisha charcoal briquette forming line. By adding binders and reformatting, the production of hookah charcoal is complete.

Applications

Due to the good properties of this charcoal, besides being used as hookah carbon, it can also be used for barbecue charcoal, soil remediation, activated carbon, metallurgy, factory fuel, and so on. When you need this equipment, please tell us your needs in time. This way Sure-Origin can customize the right production line for you.

Technical Parameters

Model	TMT-J12	TMT-J18	TMT-J40	TMT-05 Pro (skid-mounted)	TMT-10	TMT-30	TMT-50
Input Capacity	12m³/batch	18m³/batch	40m³/batch	0.3-0.5m³/h	2-4m³/h	7-9m³/h	10-15m³/h
Reactor Size	φ1900mm * L4500mm	φ1900mm * L6600mm	φ2800mm * L7100mm	φ830mm * L5500mm	φ1300mm * L14051mm	φ1700mm * L14180mm	φ2000mm * L14260mm
Land for Equipment (LWH, Standard Configuration)	9m6m6m	12m6m7m	15m18m7m	10m8m3.9m	29m15m5m	30m15m8m	35m18m9m
Weight (Standard Configuration)	18T	22T	34T	15T	35T	35T	49T
Energy Consumption (Standard Configuration)	11kw/h	13.5kw/h	25kw/h	31kw/h	34.7kw/h	61.5kw/h	116kw/h
Working Method	Batch			Fully continuous
Feeding Requirement	/			Size: ≤20mm; moisture: ≤15%; strong liquidity
Structure	Horizontal rotation			Double barrel single hearth	Double barrel double hearth
Speed	0-2RPM			1-9RPM
Control Method	Control by buttons			Automatic control
Reactor Material	Q245R				Q245+310S
Pressure	Micro negative pressure
Heating Material	Diesel, natural gas, heavy oil, biomass, etc.
Heating Method	Direct heating
Noise (dB)	≤80
Condenser	Circulating water cooling
Rotation Method	External gear rotation
